METERY TECHNOLOGY LIMITED

---

Model Series:  MT100E-Y
Sensor Type: Flange Pipe
DN Size: 10-3000MM
Accuracy: 0.5%
Liner Material Options:  PTFE, FEP,F4, Rubber.,etc
Electrode Material:  Fixed type, SS316L. Hastelloy B, Hastelloy C, Titanium Alloy.,etc
PN Grade: DN15-150  4.0Mpa, DN15-DN600 1.6Mpa, DN200-DN1000 1.0Mpa
Signal Outputs: 4-20mA, Pulse
Communications:  Modbus, Profibus, Hart, RS485, RS232.,etc
Display: Back-lit LCD,  display Instant and accumulating Data
Flange Types Options: GB,ANSI/ASME, DIN, JIS.,etc
Ex-proof option: Exdmb II CT6
Protection Grade:  IP65

More specifications and specific model codes of electromagnetic flowmeter please refer to our sales, or download brochure.
